LEICA RUGBY 50 SELF-LEVELING LASER
Simple, one-button operation, fully automatic, general construction laser. The Leica Rugby 50 has the features needed to get the job done.
Rugged, reliable, accurate. The Leica Rugby 50 is the affordable “little brother” of the popular Leica Rugby 100. The Rugby 50 provides value where ever it is used. Work gets done faster and more accurately, providing savings in labor, time and materials. As a contractor, you know the values of lasers. Built to Leica Geosystems’ tough standards, you can trust the Leica Rugby 50 to provide you with the right tool to get the job done.
Always automatic - Always self-leveling
The Leica Rugby 50 is designed to always turn on in automatic self-leveling mode. No concerns for setting up the laser incorrectly. Set up the Leica Rugby 50 within its wide leveling range, the instrument will automatically self-level and work can begin
H.I. (Elevation) Alert
The H.I. or Elevation Alert function monitors the leveling of the Leica Rugby 50. Any significant disturbance or movement of the tripod will cause the alert function to activate. The Leica Rugby 50 will stop operation and will sound an alarm to prevent possible errors.
Out of level indication
During normal operation, the Leica Rugby 50 continuously self-levels. Small vibrations and disturbances may cause an out of level condition. The head will stop momentarily and the emission LED will blink until the unit re-levels and work can resume.
The Leica Rugby lasers are available with a 2 year warranty after product registration.
- Simple, one button operation
- Choice of two levelers
- High impact composite housing
- Fully sealed with enclosed head
- Watertight for all conditions
- Long battery life - up to 60-hours
- H.I. (Elevation) alert protection
- Out of level alert
- Low battery indicator
- Optional alkaline or NiMH batteries
- 2-year warranty
Color Infrared Wavelength 780 nm Classification Class I Direction Horizontal Visibility Barely Exterior up to 1,000 ft (300 m) Self Leveling ±5 degrees (horizontal) Battery Life with Rechargeable Battery Pack 35 hours Battery Life with Alkaline Batteries 60 hours Power Source NiMH rechargeable pack or 2 "D" Alkaline batteries Battery Life Alert Flashing LED Display LED lights Bump Sensor (H.I./Out of Position Alert) Height of Instrument & Out of position alerts Protection Class IP55 Adjustable Rotating Speed 600 RPMs One-Touch Commands Yes Weight 4.0 lbs. (1.85 kg) Dimensions 6.2 x 6.4 x 6.5 in. (158 x 163 x 166mm) Warranty up to 2-years Detector/Reciever "Rod-Eye Pro" Laser - Basic or Plus Horizontal ±3/32 in. at 100 ft (±2.6mm at 30m) Storage -40°F to 158°F (-40°C to 70°C) Operating -4ºF to 122ºF (-20ºC to 50ºC) Input 100-240 VAC, 55-60 Hz Output 7.5 VDC Charging Time 8 hours Automatic Leveling Yes Checking/Setting Elevations Yes Concrete Forms, Footings and Foundations Yes
